  Key Specifications
  Details
  Key Specifications

  Specification Details:

  Space Envelope Width: 30mm

  Height: 50mm

  Closed Length: 150-2000mm

  Extension Length: 150-2000mm

  Maximum Load Capacity: 140-380 kg/pair

  Number of beams: 3

  Extension Type: Total

  Material: Zinc plated steel

  Vibration Resistence: 8

  Profile:

  Suitable For:
  DEFENCE - Airborne - Shipborne - Vehicles
  FIRE - Slide Drawers - Systems - Trays
  FOOD TRUCK - Stowage & Sliding Drawers
  FURNITURE - Architecture - Sliding Units
  MARINE - Non-Corrosive - Merchant Vessels - Oil Rigs
  SPECIAL VEHICLES - Coachbuilding - Response Vehicles
  TRAINS - Battery Rafts - Doors - Seating

  Details

  The DTS-50 is particularly suited for dynamic loading where shock and vibration with torsional demands is required. Having a very low 50mm profile, this makes it an excellent choice for vehicle mounted pumps and generator carriers, where space is restricted. This is an extreme load/duty full extension telescopic slide (140–380Kg/pair) suitable for a wide range of applications. At 550mm 1 pair has a full extension load capacity of 370Kg.

  Constructed from cold drawn steel sections, with machined ball tracks for accuracy, it has excellent levels of shock and vibration resistance. Accordingly, the product is well suited to supporting generators and heavy machine guards, even with an over extension of 120%. Due to the extreme strength of the mobile 'I' beam, this slide is robust to applied loads when in the extended position making it an excellent choice for dynamic applications. Unlike many other slides manufactured from rolled steel 'C' sections. There are no plastic parts in the manufacture of this range, making it ideal for high temperature use.

  The DTS-50 slide may also be used in the minor axis (flat) but the load capacity will be reduced to approximately 60% (depending on slide length) with an increase in deflection. A single DTS-50 weighs 9.05kg per metre.

  The slides are manufactured from cold drawn steel C45E+C in accordance with EN 10277. Standard ball cages are manufactured from zinc plated sheet metal and the ball bearings are carbon steel C85 G100 in accordance with DIN 5401. The DTS-50 is now available in steel, stainless steel and aluminium interchangeable formats.

  The DTSB version of this slide is fitted for an extension front and rear, equal to the closed length. Please ask our engineers for further information.

  The DTS-50 can be purchased online for global delivery by clicking this link. The DTS-50 is stocked across all lengths, however please allow 3-4 weeks for OEM volumes or consult our sales engineers to confirm best availability.
